One Technical Data

Home / One Technical Data
Hardware Architecture ARM® CORTEXTM – M4F PROCESSOR CODE
Wi-FiIEEE 802.11 b/g/n -2.4 GHz Security WPA/WPA2,
Encryption WEP/TKIP/AESWEP, (uFL connector available)
Voltage Input24 VDC (+10% – 5%) (5A Max)
Digital Outputsno.3 Open Collectors (Max 3A)
no.1 PWM for Coil Operation
Digital Inputsno.3 Inputs (24 VDC)
Analog Inputsno.4 Inputs
(no.2 – 0…10VDC)/ (no.2 – 4…20mA), 12 Bit
USBno.1 USB 2.0
HousingNylon PA66
Housing GasketSilicon
Protection ClassIP 67
Case InstallationEN 175301-803 (EX DIN 43650/A), 2P+E, IP67
CableLine Lenght 1M (PVC)
Other Lenght and Material Available
EnvironmentOperating: -10…50°C (14…122°F)
Storange: -25…70°C (13…158°F)
ApprovalsCE,EMC,RED
WeightApprox. 80g (Without cable)
Dimension
